Hrc45 2 Flutes Ball Nose End Mill

CNC Cutting Tools Tungsten Carbide Ball Nose End Mill for Stainless Steel

Carbide end mill

Brand name: NEUBURG
Cutter type：Ball Nose End Mill, spherical face milling
No. of flutes: 2F
material：solid carbide
Coating：TISIN
Helix angle：30°deg
Suitable for steel up to HRC50 processing,carbon steel,cast iron machining
Processing：shoulder milling, face milling,slotting,pocketing
Application: CNC machining center
Product features:
1.choosing high performance coating AlCr series, high temperature resistance and high durable;
2.suitable for oil mist cooling,water cooling,air cooling etc enviroment
Transport: TNT/UPS/DHL/Fedex/EMS

Shoulder Slotting Face

Product Description Product size

Carbide End Mill Specifications

Brand Name	NEUBURG
HRC	45/55/58/60/65/70
Flutes	2-6 Flutes
Material	Carbide, Tungsten Cobalt Alloy, Carbide, Tungsten Cobalt Alloy, Coated Carbide
Coating	AITIN, TIAIN, TICN, Tin, 5070, AITIN, TIAIN, TICN, Tin, another coating available
Precision	High Precision
Controlling Mode	CNC
Processing Type	Metal/general use
Usage	High Speed Cutting
Suitable for	Copper, Cast Iron, Carbon Steel, Mould Steel etc.
MOQ	5 Pieces

Key Features:

R	L	D
RO.5	50	d4
R0.75	50	d4
R1	50	d4
R1.25	50	d4
R1.5	50	d4
R2	50	d4
R2	75	d4
R2	100	d4
R2.5	50	d6
R2.5	75	d5
R2.5	100	d5
R3	50	d6
R3	75	d6
R3	100	d6
R3	150	d6
R4	60	d8
R4	75	d8
R4	100	d8
R4	150	d8
R5	75	d10
R5	100	d10
R5	150	d10
R6	75	d12
R6	100	d12
R6	150	d12
